Product Details
¦ Compact,Agile,Light,Reliable,Convenients,High Quality.
¦ Suitable for dry fields in plain, mountain and hilly areas. Attached with the implements, it could finish the work of tilling, plowing, mowing, reaping, harvesting, irrigating and so on. When attached the trailer, it also could be used for the short distance transportation.
¦ Can be used as a stationary power source for drainage and irrigation.
¦ With quick coupling,easy to chang farming implements.
¦ Different product colors is optional, to adapt to different market
Model | MS150 Tractor | |
Structure weight KG | Without rotavator | 363 |
With rotavator | 468 | |
Working weight (with rotavator) KG | 508 | |
Overall dimensions (LxWxH) mm | 2680 x 960 x 1250 | |
Number of blades PCS | 18 | |
Rototilling width mm | 600 | |
Type of tractor | Single axle, dual-purpose for both traction & drive | |
Travelling speed Km/h Forwrd | 1.4,2.5,4.1,5.3,9.4,15.3 | |
Travelling speed Km/h Reverse | 1.1, 3.8 | |
Type size | 4.00-10, 6.00-12 | |
Wheel track mm | 800, 740, 640, 580(normally use 800) | |
Min. ground clearance mm | 185 | |
Min. turning radius m | 0.9 with no rotavato | |
Model of engine | S1100N | |
Type of engine | Horizontal 4-stroke | |
Bore x stroke mm | 100*115 | |
Total displacement L | 0.903 | |
Compression ratio | 19.5:1 | |
Turing speed of crankshaft rpm | 2000 | |
1-hour rated output KW/hphp | 10.5/14.3 | |
12-hour rated output KW/hp | 9.8/13.33 | |
Specific fuel consumption g/kw.h | =250 | |
Specific lube oil consumption g/kw.h | =2.00 | |
Cooling mode | Condenser (Radiator) |
