Parameter

All of these models can be customized according to customer requirements.

With Certification: CE, ISO9001

NO.	Description	Parameter
1	X,Y,Z working area	2000*3000*200mm
2	Drive and motor	Yako stepper motor/driver; yaskawa servo motor/driver
3	Spindle	3kw/4.5kw/6kw watercooling spindle; 3kw/4.5kw/6kw HSD aircooling spindle.
4	Inverter	Delta frequency inverter
5	Control system	NCstudio/ Mach3/DSP controller
6	X, Y, Z Travelling Positioning Accuracy	±0.05/300mm
7	X, Y, Z Travelling Repositioning Accuracy	±0.05mm
8	Frame	Big thickened Steel Square Tubes, thickness up to 8mm
9	X, Y structure	Rack and pinion, Hiwin square rails on X, Y axis
10	Z structure	Taiwan TBI Ballscrew, Hiwin square rails on Z axis
11	Max Rapid Travel Rate	30,000mm/min
12	Max working speed	18,000mm/min
13	Working voltage	AC220V/380V, single/three phase
14	Command languages	G code
15	Running Environment  Temperature	0 degree - 45 degree
16	Software	Type3 English version; Artcam English version
17	Net weight	2100KGS
18	Gross weight	2300KGS
19	Relative Humidity	30% - 75%
20	Guarantee	One year from the date of commission
21	Optional Accessories	?Rotary system ?Mist-cooling system ?Dust collector/ Dust hoods for three axis ?Vacuum pump ?850w Yaskawa/800W Panasonic Servo motors



---

Application

1. Wooden plate processing: wood carving, cutting, hollowing-out and hole-drilling on the three

dimensional wave board processing, wooden doors, window processing, cabinets doors and panels,

computer table and Plate furniture auxiliary processing.

2. Advertising industry processing: Acrylic cutting, Advertising signs, logo production, forming system

module, a variety of the production of advertising decorative products.

3. Mold material industry: the wooden, copper, aluminumand other metal molds, as well as artificial marble,

sand, plastic sheeting, PVC pipe, and other non-metallic mold.

4. Other: Acrylic cutting machine, china cnc router. Aeronautic wood mold, propeller, automotive froth mold.

Three-dimensional curved surface of instruments like violin, erhu, dance and etc, Also suitable for engraving

and cutting on iron plate and the other metal material.



---

Youtube link:

NO1.  jinan apexcnctech 2030 cnc machine video

NO2.  jinan apexcnctech 2030 cnc machine video



---

FAQ:

1. Guarantee & After-sale Service?

1.1 One year warranty under normal use and we supply lifetime maintenance;

1.2 Technical support by Phone, Email, Skype, WhatsApp, MSN around the clock;

1.3 Free Training to make sure you master the operation of the CNC Router;

1.4 Friendly English Operation Manual, popular and easy to understand.

2. OEM Service Available?

2.1 Usually, we will manufacture the machine as our regular design;

2.2 X,Y,Z Working Area could be customer-oriented designing;

2.3 Special configuration could be customer-oriented designing.

3. Delivery Time( Production Procedure)?

3.1 For 3 Axis Machine with standard specification, usually 25 working days;

3.2 For 4 Axis Machine with standard specification, usually 35 working days;

3.3 For 5 Axis Machine, OEM or Non-standard models, usually 95 working days.

---
