P6.67mm Carbon Rental LED display
6.67mm pixel pitch, 22497 pixels per square meter, 48x24 pixels module resolution, 320×160mm module size; available cabinet size: 640×640mm, 960×960mm die-casting Carbon cabinet or other customized size;
6.67mm LED Display have unequalled high brightness, high gray grade, high fresh frequency, high contrast ratio, high waterproof and dustproof grade-IP65;
More and more customer like smaller and smaller pixel pitch LED display, so 6.67mm pixel pitch LED display taking place P8mm, P10mm, P12mm, P16mm, P20mm LED display rapidly now.
Pixel Pitch(Unit:mm): 6.67
Scanning method(1/X): 1/6
Module size: 320mm*160mm
LED lamp encapsulation type: SMD3535
Module resolution(Unit:Pixel): 48dot*24dot
Brightness: 5800-6500cd/?
Hub Port type: HUB75
Module Quantity(pcs/?): ˜19.5PCS
Pixel density(pixels/?): 22500/?
Module Power consumption(W/module): 40W
Module Weight (KG/module): 0.546KG
Average Power consumption(W/?): 320W
Max Power consumption(W/?): 780W
cabinet introduction
cases
specifications
Model | Outdoor | Outdoor |
Pixel Pitch(Unit:mm) | 6.67 | 6.67 |
Pixel confirguration/LED lamp's encapsulation type | 3535 | 3535 |
Scanning method | 1/6 | 1/6 |
Pixel density(Unit:pixels/?) | 22497 | 22497 |
Length Resolution(unit: pixel) | 48 | 48 |
Height Resolution(unit: pixel) | 24 | 24 |
Module Total Resolution(L×H)(unit: pixel) | 48×24 | 48×24 |
Module Total Dimension(L×H)(unit: mm) | 320×160 | 320×160 |
Module Total Dimension(Unit:?) | 0.0512 | 0.0512 |
Cabinet Length Resolution(unit: module) | 2 | 3 |
Cabinet Height Resolution(unit: module) | 4 | 6 |
Cabinet Total Dimension(L×H)(unit: mm) | 640×640 | 960×960 |
Cabinet Total Dimension(Unit:?) | 0.4096 | 0.9216 |
Cabinet Total Resolution(L×H)(unit: pixel) | 96×96 | 144×144 |
Color Processing Level(unit:bit) | 16bit | 16bit |
Fresh frequency(hz) | 4800 | 4800 |
Brightness:nits | 8000 | 8000 |
Module Weight(unit:KG/module) | 0.548 | 0.548 |
Module Maximum Power Consumption(unit:W/module) | 33.3 | 33.3 |
Module Maximum Current(unit:A/module) | 6.7 | 6.7 |
Cabinet Weight(unit:KG/?) | 28.0 | 28.0 |
Cabinet Weight(unit:KG/Cabinet ) | 11.5 | 25.8 |
Comprehensive LED product portfolio
More than a decade of experience with delivering successful OOH solutions
Multi award winning products and projects that are defining the future of OOH
Leading OOH companies and e.g. airports regularly use ERALED products
We offer slim and fanless solutions that are easy to install and very durable
LED display size range from ultra small to ultra large
