Customized Diameter 1350 1370 Aluminum Wire Cable for Electrical
Min.Order : 1 Pieces Quick Quotation >
Conpany Profile
Product Details
Customized Diameter 1350 1370 Aluminum Wire Cable for Electrical
TABLE 1-Textile Shield for Power Cable for Aluminum round wire
Purity | Chemical Composition% | |||||
AL | Foreign Content,Maximum | |||||
Si | Fe | Cu | V+Cr+Mn+Ti | Other | ||
Al99.60E | 99.6 | 0.08 | 0.20 | 0.005 | 0.01 | 0.3 |
Type | Tensile Strength,N/mm | Fracture Toughness%,Min | Electrical Resistance mm/m 20,Max |
A | 60-80 | 25 | 0.02755 |
A2 | 80-110 | 12 | 0.02785 |
A4 | 95-115 | 10 | 0.02801 |
A6 | 110-130 | 8 | 0.02801 |
A8 | 120-150 | 6 | 0.02801 |
TABLE 2- Tensile Property Limits for Aluminum round wire
Temper | Tensile Strength | |
Ks j | M pa | |
1350-O | 8.5-14.0 | 59-97 |
1350-H12 and-H22 | 12.0-17.0 | 83-117 |
1350-H14 and-H24 | 15.0-20.0 | 103-138 |
1350-H16 and-H26 | 17.0-22.0 | 117-152 |
TABLE 3- Electrical Resistivity Limits for Aluminum round wire
Temper | Resistivity | Equivalent Volume Conductivity,% |
Max..mm2/m | IACS Min. | |
1350-O | 0.027899 | 61.8 |
1350-H12 and-H22 | 0.028035 | 61.5 |
1350-H14 and-H24 | 0.028080 | 61.4 |
1350-H16 and-H26 | 0.028126 | 61.3 |
Aluminum Wire Rod Applications:
1.Aircraft, transport vehicles, vessels, instruments, metal products
2.Processing to the rivets, zipper.nails,etc
3.Welding Aluminium Magnesium alloy wire which magnesium content is exceeding3%
4.Sanitary equipment hose braiding materials, automotive and machinery oil hose material
5.Electronic industries and telecommunications industries
6.Textile shield for power cable
Yiwanhong is a professional customized diameter 1350 1370 aluminum wire cable for electrical manufacturer and supplier in China, offering quality and customized aluminum products with good properties and various grades. Don't hesitate to buy our quality products any more.
