DESIGN FEATURES:

• Seat faces lapped for smooth finish and superior sealing.

• Swivel disc for optimal seating and longer seat life.

• Stems of hand wheel operated valves are rotating / rising design.

• Each valve is shell, seat and backseat pressure tested per industry standard API 598.

• Gland is two piece gland / gland flange design for optimal alignment and uniform packing compression.

•Alternate valve materials such as chrome and stainless steel alloys -Alternate trim materials -Bypass, drain and other auxiliary connections -Gear, motor, and cylinder actuators available

•NACE service

•Special cleaning for applications such as oxygen or chlorine

Rate Range:Class 150 to Class 2500

Size Range:2? to 24?

Materials:CF8/CF8M/CF3/CF3M/duplex stainless steel/alloy

Operation:wheel/Bevel Gear/Air Cylinder/Hydraulic Cylinder/Electric actuator

Type:BOLTED BONNET/Pressure Seal

Design Specifications:

Wall thickness: BS1873/API603/ASME B16.34

Pressure-temperature ratings:ASME B16.34

General valve design:BS1873/API623/B16.34

End to End dimensions:ASME B16.10

Flange design:ASME B16.5

Butt weld design:ASME B16.25

Materials:ASTM
