Find high quality sb114nc hydraulic pipe bender with competitive price here. Please rest assured to buy sb114nc hydraulic pipe bender with SHN CNC machinery Co., Ltd

Main specifications

Maximum bending diameter x wall thickness: f 114x15mm

Maximum bending radius: R650mm

Minimum bending radius: R90mm

Maximum bending angle: 190 °

Standards through the length: 5500mm

Control system: micro-computer control

Pipe maximum allowable number of elbows: 16 Pack

Can store the number of parts: 16x16

Motor power: 18.5kW

Maximum pressure: 14mpa

Hydraulic system control: solenoid valve

Fuel tank capacity: 420L

Machine size: 7500x1300x1450mm

Weight: 6500kg

Minimum bend RADIUS must not be less than the diameter of 1.3D; maximum bend RADIUS, the maximum effective through length can be customized according to customer requirements.
