Ton bag bagging machine is also known as jambo bag packing machine, it is widely used for the packing solution for wood pellets, feed pellets, fertilizer pellets, industrial material granular and powder material.
Material go to weighing device from hopper, the weighing device is controlled by electric panel, it can weight the material to a presetting value with high accuracy, the bag clamp system can automatic unclamp the ton bag after the material fill into bag, the conveyor under the machine can move the bag away.
The weighing system apply fast add, medium add and slow add three step to get the presetting weight value, thus to make sure the weighing accuracy.
Easy to set the weighing value from electric panel.
Manually put bag to bag clamp device
Ton bag bagging machine drawing
Ton bag bagging machine technical data
Model | JT1000 |
Weighing range | 100-2000Kg |
Feeding motor power | 1.5kw |
Voltage | AC380V/220V, 50Hz or customized |
Compressed air pressure | 0.6Mpa |
Compressed air consumption | 0.08m³/min |
Error | ±0.2% |
Packing speed | 10-40 bags per hour |
Bag size | 1100x1100x1100mm |
Bag inlet size | F400mm |
Gallus of bags | Four gallus 400mm lengt |
Main body dimension | 2000x2000x4400mm |
Conveyor width | 1400mm |
Conveyor length | 1500mm+2500mm |
Conveyor power | 1.5+2.2Kw |
Working temperatur | -20?~+40? |
Bag sealing method | Manually sealing |
