Find high quality tuv solar cable with competitive price here. Please rest assured to buy tuv solar cable with Huzhou Permanent Cable Co.,Ltd

Quick Details
Place of Origin:Zhejiang, China (Mainland)
Brand Name:Permanent
Model Number:TUV
Insulation Material:XLPE
Type:Medium Voltage
Application:Connect photovoltaic system components
Conductor Material:Tinned Copper
Jacket:XLPE
Standard:UL& TUV
Construction:Tinned copper conductor XLPE insulation XLPE sheath
Voltage:0.6/1kv
Core Color:Red,black
Main Markets:Worldsize
Factory:2h from Shanghai
Business Type:Manufacture
Delivery:Sea

Packaging & Delivery

Packaging Details:	Plastic reel, wooden drum, coils,carton
Delivery Detail:	within 20 days

Specifications
tuv cable
1.Virgin raw material for the best quality
2.Factory sale prices
3.Free samples
TUV Certification Tinned Copper Wire Solar PV Cable one or two Core
Application
The cable is used for connecting photovotaic system components inside and outside
of building and equipment with high mechanical requirements and extreme weather conditions
Standard
UL& TUV
Technical date
Conductor:Copper/Aluminum
Insulation:XLPE
Sheath:XLPE
Voltage:0.6/1KV
Package:Wooden drum package or Iron-wooden drum.

specification

Cross Section Area mm	No./Diameter of conductor mm	Insulation thickness mm	Sheath thickness mm	Overall Diameter mm
1.5	30/0.25	0.6	0.6	4.7
2.5	51/0.25	0.6	0.7	5.2
4	56/0.3	0.6	0.7	6.1
6	84/0.3	0.8	0.8	7.2
10	142/0.3	0.9	0.9	9
2x1.5	2x30/0.25	0.6	0.6	9.4x4.7
2x2.5	2x51/0.25	0.6	0.7	10.4x5.2
2x4	2x56/0.3	0.6	0.7	12.2x6.1
2x6	2x84/0.3	0.8	0.8	14.4x7.2
2x10	2x142/0.3	0.9	0.9	18x9
