Product description:
1? using the inverter technology and imported the most advanced IGBT module, elaborate, inverter frequency up to 20KHz, faster dynamic response, perfect function, good performance, high reliability, high quality welding can meet the engineering requirements, the user is reliable welding equipment;
2?high load duration, welding power margin, long-term welding, work cable extension, 100M can still be stable welding;
3?it has the function of automatic compensation of voltage fluctuation, strong resistance to power grid fluctuation and stable and reliable welding current;
4?it has thrust compensation function, good arc stability, uniform molten pool, minimal spatter and beautiful weld formation, regardless of size and current;
5?the use of cellulose welding rod for downward welding. Also applicable to all kinds of brand welding rod, especially applicable to alkaline welding rod, welding all kinds of low, medium carbon steel, low alloy steel, stainless steel and so on;
6?the utility model can be used for the carbon arc air gouging function, and has the advantages of one machine and multiple functions;
7? widely used in petroleum pipelines, chemicals, automobiles, shipbuilding, boilers, power construction, nuclear power, aerospace, military, industrial installations, bridges, construction and other industries welding
Technical Parameters | ||
Model | ARC/ZX7-400G | ARC/ZX7-400 |
Rated input voltage /frequency | Three Phases 380V±15% 50/60Hz | |
Rated input capacity (KVA) | 18.4 | 18.4 |
Rated input current (A) | 28 | 28 |
Rated output voltage (V) | 36 | 36 |
Rated duty cycle (%) | 60 | 60 |
Output noload voltage (V) | 68 | 73 |
Output current range (A) | 20-400 | 20-400 |
Enclosure protection class | IP21S | |
Insulation grade | F | |
Type of cooling | Air Cooling | |
Exterior size LxWxH(mm) | 582x342x457 | 693x413x640 |
Weight(kg) | 22 | 43 |
